Caterpillar 926K
Browse All Caterpillar or Wheel Loader Models
Contents:
Dimensions
| Ground Clearance | 0.94 ft in (286.52 mm) |
| Length With Bucket On Ground | 21.6 ft in (6583.68 mm) |
| Width Over Tires | 7.6 ft in (2316.48 mm) |
| Height To Top Of Cab | 10.4 ft in (3169.92 mm) |
| Wheelbase | 9.4 ft in (2865.12 mm) |
| Hinge Pin - Max Height | 11.8 ft in (3596.64 mm) |
| Reach At Max Lift And Dump | 3.2 ft in (975.36 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2236 |
| Engine Model | 3204 |
| Net Power | 104.6 hp (78.1 kw) |
| Power Measured @ | 2400 rpm |
| Displacement | 317.3 cu in (5.2 L) |
| Aspiration | TURBOCHARGED |
Operational
| Operating Weight | 20498.6 lb (9298.1 kg) |
| Fuel Capacity | 39.6 gal (150 L) |
| Hydraulic System Fluid Capacity | 24.3 gal (92 L) |
| Engine Oil Fluid Capacity | 3.7 gal (14.1 L) |
| Transmission Fluid Capacity | 9 gal (34.1 L) |
| Front Axle/Diff Fluid Capacity | 6.6 gal (25 L) |
| Rear Axle/Diff Fluid Capacity | 6.6 gal (25 L) |
| Static Tipping Weight | 15220.7 lb (6904 kg) |
| Turning Radius | 16.7 ft in (5090.2 mm) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 amps |
| Rear Axle Oscillation | 30 degrees |
Transmission
| Transmission Type | POWERSHIFT |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
| Max Speed - Forward | 18.8 mph (30.3 km/h) |
| Max Speed - Reverse | 20.1 mph (32.4 km/h) |
Hydraulic System
| Relief Valve Setting | 2500 psi (17236.9 kPa) |
| Pump Flow Capacity | 40.2 gal/min (152.2 L/min) |
| Raise Time | 5.9 sec |
| Dump Time | 1.6 sec |
| Lower Time | 3.6 sec |
