John Deere 3156G
Browse All John Deere or Log Loader Models
Contents:
Dimensions
| Overall Width | 11.91 ft in (3630 mm) |
| Length Of Track On Ground | 13.33 ft in (4060 mm) |
| Track Gauge | 9.59 ft in (2920 mm) |
| Ground Clearance | 2.6 ft in (790 mm) |
| Overall Track Length | 16.41 ft in (5000 mm) |
| Overall Length | 583.08 in (14810 mm) |
| Tailswing Radius | 11.91 ft in (3630 mm) |
| Horizontal Reach | 36.32 ft in (11.07 m) |
| Transport Height | 12.18 ft in (3710 mm) |
| Width Over Tracks | 11.91 ft in (3630 mm) |
Driveline
| Engine Model | PowerTech PSS 9.0L |
| Displacement | 549.3 cu in (9 L) |
| Engine Manufacturer | John Deere |
| Engine Output | 249.5 hp (186 kw) |
| Engine Output - Net | 249.5 hp (186 kw) |
| Carrier Rollers - Each Side | 2 |
| Track Rollers - Each Side | 8 |
| Track Shoe Width | 27.6 in (700 mm) |
Capacities
| Fuel Tank - Diesel | 285.4 gal (1080 L) |
| Hydraulic Tank | 51.6 gal (195 L) |
Performance
| Travel Speed | 2.7 mph (4.2 km/h) |
| Ground Bearing Pressure | 10.9 psi (74.9 kPa) |
| Lift Capacity At Max - Reach | 16049.7 lb (7280 kg) |
| Slew Torque | 88507 lb ft (119999.4 Nm) |
| Pump Flow | 65.6 gal/min (248 L/min) |
| Relief Pressure | 4974.8 psi (34300 kPa) |
| Pump Type | Variable Axial Piston |
| Boost Pressure | 5511.5 psi (38000 kPa) |
Weights
| Operating Weight | 93870.7 lb (42579 kg) |
