Terex AC205
Browse All Terex or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 35.77 ft in (10.9 m) |
| Max Height @ Max Raise Angle - No Jib | 164.05 ft in (50 m) |
| Number Of Sections | 6 |
Dimensions
| Transport Length | 39.74 ft in (12110 mm) |
| Transport Width | 9.03 ft in (2750 mm) |
| Transport Height | 11.77 ft in (3585 mm) |
| Width W/ Outriggers Extended | 22.97 ft in (7000 mm) |
| Carrier Length | 32.71 ft in (9970 mm) |
| Upper Structure Tail Swing Radius | 12.14 ft in (3700 mm) |
Upper Structure Engine
| Make | Terex |
Carrier Engine
| Make | Terex |
| Model | OM 402 LA |
| Gross Power | 375.5 hp (280 kw) |
| Power Measured @ | 2100 rpm |
| Max Torque | 1309.2 lb ft (1775 Nm) |
| Torque Measured @ | 1200 rpm |
Operational
| Number Of Axels | 4 |
| Carrier Fuel Capacity | 105.7 gal (400 L) |
| Operating Voltage | 24 V |
| Tire Size | 16.00 R 25 |
Transmission
| Transmission Type | Allison automatic |
