Schaffer 9100ZS
Browse All Schaffer or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 8.86 ft in (2700 mm) |
| Bucket Capacity - Heaped | 1.31 yd3 (1 m3) |
| Breakout Force | 6069.85 lb (27 kN) |
Dimensions
| Length With Bucket On Ground | 14.93 ft in (4550 mm) |
| Width Over Tires | 6.73 ft in (2050 mm) |
| Height To Top Of Cab | 8.08 ft in (2460 mm) |
| Wheelbase | 7.12 ft in (2170 mm) |
| Hinge Pin - Max Height | 11.16 ft in (3400 mm) |
| Reach At Max Lift And Dump | 1.53 ft in (465 mm) |
Engine
| Engine Make | 2349 |
| Engine Model | BF4M2012 |
| Gross Power | 130 hp (97 kw) |
Operational
| Operating Weight | 13227.8 lb (6000 kg) |
| Fuel Capacity | 25.1 gal (95 L) |
| Hydraulic System Fluid Capacity | 27.8 gal (105 L) |
| Static Tipping Weight | 9700.4 lb (4400 kg) |
| Tire Size | 405x70-20 |
Transmission
| Transmission Type | hydrostatic |
| Number Of Forward Gears | 2 |
| Number Of Reverse Gears | 2 |
| Max Speed - Forward | 19.9 mph (32 km/h) |
| Max Speed - Reverse | 19.9 mph (32 km/h) |
Hydraulic System
| Relief Valve Setting | 7000 psi (48263.3 kPa) |
| Pump Flow Capacity | 52.4 gal/min (198 L/min) |
