Terex TH636C
Browse All Terex or Telescopic Forklift Models
Contents:
Dimensions
| Ground Clearance | 1.42 ft in (430 mm) |
| Overall Height | 8.34 ft in (2540 mm) |
| Wheelbase | 10.34 ft in (3150 mm) |
| Overall Width | 8.5 ft in (2590 mm) |
| Max. Reach @ Full Height | 2.5 ft in (0.76 m) |
| Turning Radius Outside Tires | 12.93 ft in (3940 mm) |
| Overall Length | 22.41 ft in (6830 mm) |
Lift
| Max Lift Height | 36.09 ft in (11000 mm) |
| Max Forward Reach | 21 ft in (6400 mm) |
| Payload At Max Reach | 1995.19 lb (905 kg) |
| Payload At Max. Lift Height | 6000.99 lb (2722 kg) |
| Max Lift Capacity | 6000.99 lb (2722 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | John Deere |
| Engine Model | 4045T |
| Gross Power | 99 hp (73.9 kw) |
| Power Measured @ | 2500 rpm |
Operational
| Operating Weight | 21080.7 lb (9562 kg) |
| Fuel Capacity | 30 gal (113.6 L) |
| Hydraulic System Fluid Capacity | 34 gal (128.8 L) |
| Tire Size | 1300 x 24-12 ply |
| Travel Speed | 17.3 mph (27.7 km/h) |
Transmission
| Number Of Forward Gears | 3 |
