Terex T200
Browse All Terex or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 13.78 ft in (4200 mm) |
| Ground Clearance | 1.12 ft in (340 mm) |
| Width Over Tires | 6.4 ft in (1950 mm) |
| Overall Height | 7.98 ft in (2430 mm) |
| Wheelbase | 7.22 ft in (2200 mm) |
| Turning Radius Outside Tires | 11.88 ft in (3620 mm) |
Lift
| Max Lift Height | 15.26 ft in (4650 mm) |
| Max Load At Max Reach | 2204.63 lb (1000 kg) |
| Max Lift Capacity | 4409.25 lb (2000 kg) |
Engine
| Engine Make | 2351 |
| Engine Model | 1104-44T |
| Net Power | 100.1 hp (74.6 kw) |
| Aspiration | turbo |
Operational
| Fuel Capacity | 24.1 gal (91 L) |
| Hydraulic System Fluid Capacity | 24.1 gal (91 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 amps |
| Tire Size | 405/70-20 |
Transmission
| Transmission Type | ITL |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
Hydraulic
| Pump Flow Capacity | 23 gal/min (87 L/min) |
