Terex SS-842C
Browse All Terex or Telescopic Forklift Models
Contents:
Dimensions
| Ground Clearance | 1.35 ft in (410 mm) |
| Overall Height | 9.09 ft in (2770 mm) |
| Wheelbase | 10.83 ft in (3300 mm) |
| Overall Length | 24.02 ft in (7320 mm) |
| Overall Width | 8.01 ft in (2440 mm) |
| Turning Radius Outside Tires | 14.77 ft in (4500 mm) |
Lift
| Max Lift Capacity | 8000.58 lb (3629 kg) |
Engine
| Engine Make | John Deere |
| Engine Model | 4045T |
| Gross Power | 100 hp (74.6 kw) |
| Power Measured @ | 2500 rpm |
Operational
| Operating Weight | 22090.4 lb (10020 kg) |
| Fuel Capacity | 30 gal (113.6 L) |
| Tire Size | 1300 x 24 - 12 Ply |
| Travel Speed | 17.3 mph (27.7 km/h) |
Transmission
| Number Of Forward Gears | 3 |
Weights
| Front Axle Weight | 8113.1 lb (3680 kg) |
| Rear Axle Weight | 13977.4 lb (6340 kg) |
Hydraulic
| Pump Type | Flow on Demand |
Brakes
| Service Brake | Enclosed, Hydraulic, Multiplate, Oil Cooled |
| Parking Brake | Spring Applied/Hydraulic Release Disc |
