Terex TH842C
Browse All Terex or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 24.02 ft in (7320 mm) |
| Ground Clearance | 1.42 ft in (430 mm) |
| Width Over Tires | 8.5 ft in (2590 mm) |
| Overall Height | 9.09 ft in (2770 mm) |
| Wheelbase | 10.83 ft in (3300 mm) |
| Turning Radius Outside Tires | 14.77 ft in (4500 mm) |
Lift
| Max Lift Height | 42 ft in (12801.6 mm) |
| Max Forward Reach | 25 ft in (7620 mm) |
| Max Lift Capacity | 8000 lb (3628.74 kg) |
Engine
| Engine Make | 2240 |
| Engine Model | 4045T |
| Gross Power | 99 hp (73.9 kw) |
| Power Measured @ | 2500 rpm |
| Aspiration | Turbocharged |
Operational
| Operating Weight | 22500 lb (10205.9 kg) |
| Fuel Capacity | 30 gal (113.6 L) |
| Hydraulic System Fluid Capacity | 34 gal (128.8 L) |
| Alternator Supplied Amperage | 95 amps |
| Tire Size | 1300x24 12 ply |
Transmission
| Transmission Type | Powershift |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 17.2 mph (27.7 km/h) |
| Max Speed - Reverse | 17.2 mph (27.7 km/h) |
Hydraulic
| Pump Type | Axial Piston |
