Bobcat V723FL
Browse All Bobcat or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 16.72 ft in (5094 mm) |
| Ground Clearance | 20.2 ft in (513 mm) |
| Width Over Tires | 7.27 ft in (2215 mm) |
| Overall Height | 7.79 ft in (2372 mm) |
| Wheelbase | 9.36 ft in (2850 mm) |
| Turning Radius Outside Tires | 12.8 ft in (3900 mm) |
Lift
| Max Lift Height | 23.64 ft in (7205 mm) |
| Max Forward Reach | 13.05 ft in (3975 mm) |
| Max Load At Max Reach | 3000 lb (1360.78 kg) |
| Max Load At Max Height | 7000 lb (3175.15 kg) |
| Max Lift Capacity | 7000 lb (3175.15 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2351 |
| Engine Model | 1104C-44T |
| Net Power | 100 hp (74.6 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 304 lb ft (412.2 Nm) |
| Torque Measured @ | 1400 rpm |
| Displacement | 269 cu in (4.5 L) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 15827 lb (7179.1 kg) |
| Fuel Capacity | 38.3 gal (145 L) |
| Drawbar Pull | 10341 lb (4690.6 kg) |
| Tire Size | 400/80x24 |
Transmission
| Max Speed - Forward | 18.7 mph (30.1 km/h) |
Hydraulic
| Pump Flow Capacity | 21 gal/min (79.5 L/min) |
| Relief Valve Pressure | 3843.5 psi (26500 kPa) |
