Jonyang JYL608
Browse All Jonyang or Mobile Excavator Models
Contents:
Boom/Stick Option (Mex) 1
| Shipping Length Of Unit | 20.51 ft in (6250 mm) |
| Shipping Height Of Unit | 9.02 ft in (2748 mm) |
| Max Cutting Height | 22.41 ft in (6830 mm) |
| Max Loading Height | 16.38 ft in (4990 mm) |
| Max Reach Along Ground | 20.94 ft in (6380 mm) |
| Max Digging Depth | 12.96 ft in (3950 mm) |
| Boom/Stick Option (Mex) 1 | Stick 1780mm |
Dimensions
| Wheelbase | 7.88 ft in (2400 mm) |
| Overall Width | 7.09 in (2160 mm) |
| Ground Clearance | 0.87 ft in (263 mm) |
| Height To Top Of Cab | 9.02 ft in (2748 mm) |
| Upper Structure Clearance | 3.43 ft in (1043 mm) |
Engine
| Engine Make | 2347 |
| Engine Model | B3.3 |
| Net Power | 80.5 hp (60 kw) |
Operational
| Hydraulic System Relief Valve Pressure | 4351.2 psi (30000 kPa) |
| Hydraulic Pump Flow Capacity | 45 gal/min (170 L/min) |
Swing Mechanism
| Swing Speed | 12 rpm |
Transmission
| Max Travel Speed | 15.6 mph (25 km/h) |
