Jonyang JY608
Browse All Jonyang or Midi Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | _ - (6215 mm) |
| Shipping Height Of Unit | _ - (2520 mm) |
| Max Cutting Height | 23.09 ft in (7035 mm) |
| Max Loading Height | 16.66 ft in (5075 mm) |
| Max Reach Along Ground | 21.23 ft in (6470 mm) |
| Max Digging Depth | 13.79 ft in (4203 mm) |
| Boom/Stick Option (Hex) 1 | Boom 5700mm/Stick 3000mm |
Dimensions
| Width To Outside Of Tracks | 7.22 ft in (2200 mm) |
| Length Of Track On Ground | 7.16 ft in (2180 mm) |
| Ground Clearance | 1.21 ft in (368 mm) |
| Height To Top Of Cab | 8.17 ft in (2490 mm) |
| Tail Swing Radius | 6.07 ft in (1850 mm) |
| Removal Counterweight Clearance | 2.65 ft in (806 mm) |
Undercarriage
| Shoe Size | 17.72 in (450 mm) |
| Track Gauge | 5.75 ft in (1750 mm) |
| Max Travel Speed | 2.8 mph (4.5 km/h) |
| Ground Pressure | 5511.44 psi (38000 kPa) |
Engine
| Engine Make | 2347 |
| Engine Model | B3.3 |
| Net Power | 80.5 hp (60 kw) |
Operational
| Operating Weight | 16000 lb (7257.5 kg) |
| Hydraulic System Relief Valve Pressure | 4351.2 psi (30000 kPa) |
| Hydraulic Pump Flow Capacity | 42.3 gal/min (160 L/min) |
Swing Mechanism
| Swing Speed | 12 rpm |
