John Deere 50
Browse All John Deere or Mini Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 17.82 ft in (5430 mm) |
| Shipping Height Of Unit | 8.04 ft in (2450 mm) |
| Max Loading Height | 10.67 ft in (3250 mm) |
| Max Reach Along Ground | 18.25 ft in (5560 mm) |
| Max Digging Depth | 11.49 ft in (3500 mm) |
Dimensions
| Width To Outside Of Tracks | 6 ft in (1828.8 mm) |
| Ground Clearance | 1.09 ft in (330 mm) |
| Height To Top Of Cab | 8.04 ft in (2450 mm) |
| Tail Swing Radius | 4.89 ft in (1490 mm) |
Undercarriage
| Shoe Size | 14.97 in (380 mm) |
| Track Gauge | 4.73 ft in (1440 mm) |
| Number Of Carrier Rollers Per Side | 4 |
| Ground Pressure | 3.88 psi (26.76 kPa) |
| Number Of Shoes Per Side | 37 |
| Number Of Track Rollers Per Side | 1 |
| Max Travel Speed | 2.25 mph (3.61 km/h) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2348 |
| Engine Model | 4TN78T-RJB |
| Net Power | 39 hp (29.1 kw) |
| Power Measured @ | 2650 rpm |
| Displacement | 100 cu in (1.7 L) |
| Max Torque | 92 lb ft (124.8 Nm) |
| Torque Measured @ | 1800 rpm |
Operational
| Operating Weight | 9270 lb (4204.9 kg) |
| Fuel Capacity | 14.3 gal (54.2 L) |
| Cooling System Fluid Capacity | 2 gal (7.4 L) |
| Hydraulic System Fluid Capacity | 27.7 gal (104.9 L) |
| Engine Oil Capacity | 2 gal (7.5 L) |
| Swing Drive Fluid Capacity | 0.7 gal (2.3 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 35 amps |
| Hydraulic System Relief Valve Pressure | 2420 psi (16685.3 kPa) |
| Hydraulic Pump Flow Capacity | 33.4 gal/min (126.5 L/min) |
Swing Mechanism
| Swing Speed | 10.7 rpm |
Buckets
| Reference Bucket Capacity | 0.2 yd3 (0.2 m3) |
