John Deere 370
Browse All John Deere or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 36.29 ft in (11060 mm) |
| Shipping Height Of Unit | 11.42 ft in (3480 mm) |
| Max Cutting Height | 32.58 ft in (9930.39 mm) |
| Max Loading Height | 23 ft in (7010.4 mm) |
| Max Reach Along Ground | 33.75 ft in (10287 mm) |
| Max Vertical Wall Digging Depth | 17.83 ft in (5434.59 mm) |
| Max Digging Depth | 21.92 ft in (6681.22 mm) |
| Boom/Stick Option (Hex) 1 | Arm Length 8ft. 9in . (2.66m ) |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 35.77 ft in (10900 mm) |
| Max Cutting Height | 33.75 ft in (10287 mm) |
| Shipping Height Of Unit | 10.67 ft in (3250 mm) |
| Max Loading Height | 23.58 ft in (7187.19 mm) |
| Max Reach Along Ground | 35.58 ft in (10844.79 mm) |
| Max Vertical Wall Digging Depth | 20.67 ft in (6300.22 mm) |
| Max Digging Depth | 23.67 ft in (7214.62 mm) |
| Boom/Stick Option (Hex) 2 | Arm Length 10ft. 6in. (3.2m ) |
Boom/Stick Option (Hex) 3
| Shipping Length Of Unit | 36.13 ft in (11010 mm) |
| Max Cutting Height | 35 ft in (10668 mm) |
| Max Loading Height | 25.17 ft in (7671.82 mm) |
| Shipping Height Of Unit | 11.59 ft in (3530 mm) |
| Max Reach Along Ground | 38.08 ft in (11606.79 mm) |
| Max Vertical Wall Digging Depth | 23.58 ft in (7187.19 mm) |
| Max Digging Depth | 26.25 ft in (8001 mm) |
| Boom/Stick Option (Hex) 3 | Arm Length 13ft. 1in. (4.0m ) |
Dimensions
| Ground Clearance | 1.83 ft in (557.79 mm) |
| Height To Top Of Cab | 10.6 ft in (3230 mm) |
| Width To Outside Of Tracks | 10.96 ft in (3340 mm) |
| Length Of Track On Ground | 13.29 ft in (4050 mm) |
| Tail Swing Radius | 10.83 ft in (3300 mm) |
| Removal Counterweight Clearance | 4.11 ft in (1250 mm) |
Undercarriage
| Track Gauge | 8.5 ft in (2590 mm) |
| Shoe Size | 30 in (750 mm) |
| Max Travel Speed | 3 mph (4.83 km/h) |
| Ground Pressure | 7.93 psi (54.68 kPa) |
| Number Of Shoes Per Side | 49 |
| Number Of Carrier Rollers Per Side | 2 |
| Number Of Track Rollers Per Side | 8 |
| Drawbar Pull | 65098 lb (289.58 kN) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2240 |
| Engine Model | 6081H |
| Net Power | 235 hp (175.3 kw) |
| Power Measured @ | 2000 rpm |
| Max Torque | 940 lb ft (1274.5 Nm) |
| Displacement | 494 cu in (8.1 L) |
| Aspiration | Turbocharger |
| Torque Measured @ | 1100 rpm |
Operational
| Operating Weight | 81200 lb (36831.8 kg) |
| Fuel Capacity | 148 gal (560.3 L) |
| Cooling System Fluid Capacity | 14.6 gal (55 L) |
| Hydraulic System Fluid Capacity | 85 gal (321.8 L) |
| Engine Oil Capacity | 7.4 gal (28.1 L) |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 4.5 gal (17 L) |
| Alternator Supplied Amperage | 45 amps |
| Hydraulic System Relief Valve Pressure | 4624 psi (31881.4 kPa) |
| Hydraulic Pump Flow Capacity | 77 gal/min (291.5 L/min) |
Swing Mechanism
| Swing Speed | 10.9 rpm |
| Swing Torque | 67700 lb ft (91788.9 Nm) |
Buckets
| Reference Bucket Capacity | 2.4 yd3 (1.8 m3) |
