Fuchs MHL334
Browse All Fuchs or Material Handler Models
Contents:
Dimensions
| Wheelbase | 9.1 ft in (2773.68 mm) |
| Overall Height | 14.1 ft in (4297.68 mm) |
| Overall Length | 17.7 ft in (5394.96 mm) |
| Overall Width | 15.11 ft in |
| Turning Radius | 18.71 ft in (5700 mm) |
Electrical System
| Alternator | 28 V / 100 A |
| Starter | 24 V / 4.0 kW |
| Batteries | 2 × 12 V / 110 Ah / 750 A (according to EN) |
| Operation Voltage | 24 V |
| Lighting | 1 × H3 headlamp on uppercarriage 1 × H3 headlamp on cab floor rear marker lights and flashers: optional additional working floodlights H3 / LED / XENON |
Engine
| Air Filter Type | Two-stage filter with safety valve |
| Cooling Method | Coolant and charge air cooling, with temperature controlled fan speed |
| Engine Model | Deutz TCD 4.1 L4 |
| Engine Type | 4-stoke diesel engine, direct common-rail fuel-injection, turbocharger, controlled exhaust gas recirculation, diesel particulate filter with automatic regeneration |
| Gross Power | 154.3 hp (115 kw) |
| Power Measured @ | 2000 rpm |
| Displacement | 250.2 cu in (4.1 L) |
Operational
| Operating Weight W/O Attachment | 54000.1 lb (24494 kg) |
| Hydraulic System Fluid Capacity | 100.4 gal (380 L) |
Transmission
| Turning Radius | 18.8 ft in (5.7 m) |
Swing Mechanism
| Swing Torque | 35403 lb ft (48000 Nm) |
Transmission
| Max Speed | 12.5 mph (20 km/h) |
Hydraulic
| Maximum Operating Pressure | 5221.4 psi (36000 kPa) |
