Kubota BX23S
Browse All Kubota or Loader Backhoe Models
Contents:
Dimensions
| Wheelbase | 4.6 ft in (1400 mm) |
| Ground Clearance | 0.7 ft in (213 mm) |
| Front Tread Range | 36.62 in (930 mm) |
| Rear Tread Range | 32.29 in (820 mm) |
| Width | 45.08 in (1145 mm) |
| Overall Length With 3-Point Hitch | 8.26 ft in (2.52 m) |
| Height With Rops | 7.19 ft in (2190 mm) |
Engine
| Pto Horsepower | 17.7 hp |
| Engine Make | Kubota |
| Engine Model | D902 |
| Engine Type | Liquid-cooled, 3-cylinder diesel |
| Gross Power | 23 hp (17.2 kw) |
| Power Measured @ | 3200 rpm |
| Displacement | 54.8 cu in (0.9 L) |
Operational
| Fuel Capacity | 6.6 gal (25 L) |
| Operating Weight 4wd | 1569.7 lb (712 kg) |
| 3 Point Hitch Type | Optional |
| 3 Point Hitch Lift Capacity @ 24 Inches | 683.5 lb (310 kg) |
| Turning Radius | 7.6 ft in (2300 mm) |
Transmission
| Pto Option Available? | Live independent PTO (with hydraulic clutch) |
| Transmission Type | HST, High-Low gear shift ( 2 forward / reverse ) |
| Max Speed - Forward | 8.4 mph (13.5 km/h) |
| Max Speed Reverse | 6.6 mph (10.5 km/h) |
Tires
| Standard_Option_Front | 18×8.5–10 |
| Standard_Option_Rear | 26×12–12 |
Hydraulic
| Steering Type | Hydraulic power steering |
| Pump Flow Capacity | 6.2 gal/min (23.5 L/min) |
Brakes
| Brakes Type | Wet disc |
