XCMG XCT50E
Browse All XCMG or Hydraulic Truck Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 37.41 ft in (11.4 m) |
| Max Height @ Max Raise Angle - No Jib | 142.07 ft in (43.3 m) |
| Max Lift Capacity | 99999.92 lb (45359.2 kg) |
Dimensions
| Transport Length | 45.25 ft in (13790 mm) |
| Transport Width | 9.19 ft in (2800 mm) |
| Transport Height | 12.06 ft in (3675 mm) |
| Ground Clearance | 1.08 ft in (327 mm) |
| Gradeability | 40 % |
| Approach Angle | 21 degrees |
| Angle Of Departure | 15 degrees |
Carrier Engine
| Model | WD615.334 |
| Gross Power | 331.3 hp (247 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 995.8 lb ft (1350 Nm) |
| Torque Measured @ | 1400 rpm |
Operational
| Operating Weight | 93674.5 lb (42490 kg) |
Transmission
| Max Speed - Forward | 49.8 mph (80 km/h) |
