Lift King LK-AF13
Contents:
Dimensions
| Length To Fork Face | 19.42 ft in (5918 mm) |
| Overall Width | 8.5 ft in (2590 mm) |
| Wheelbase | 11.34 ft in (3454 mm) |
| Ground Clearance | 15.75 in (400 mm) |
| Height To Top Of Overhead Guard | 8.17 ft in (2490 mm) |
| Max Fork Height | 14 ft in (4267 mm) |
| Turning Radius | 19.92 ft in (6070 mm) |
Mast
| Mast Tip Forward | 10 degrees |
| Mast Tip Rear | 20 degrees |
| Load Center | 24.02 in (610 mm) |
| Load Capacity | 17636.99 lb (8000 kg) |
Engine
| Engine Make | 2236 |
| Engine Model | 3054C |
| Power | 129 hp (96.2 kw) |
| Fuel Type | diesel |
Operational
| Operating Weight | 28475 lb (12916 kg) |
| Tire Type | 16.00x24TG 16ply |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
