Lift King LK3022
Contents:
Dimensions
| Length To Fork Face | 16.84 ft in (5130 mm) |
| Overall Width | 8.42 ft in (2565 mm) |
| Overall Height - Mast Lowered | 13.84 ft in (4216 mm) |
| Wheelbase | 10.5 ft in (3200 mm) |
| Ground Clearance | 11.97 in (304 mm) |
| Height To Top Of Overhead Guard | 10.93 ft in (3330 mm) |
| Max Fork Height | 15.69 ft in (4780 mm) |
| Turning Radius | 16.17 ft in (4928 mm) |
Mast
| Mast Tip Forward | 10 degrees |
| Mast Tip Rear | 10 degrees |
| Load Center | 24 in (609.6 mm) |
| Load Capacity | 30000 lb (13607.78 kg) |
| Max Fork Spread | 85.04 in (2160 mm) |
Engine
| Engine Make | 2347 |
| Power | 152 hp (113.4 kw) |
| Fuel Type | diesel |
Operational
| Operating Weight | 46450 lb (21069.4 kg) |
| Tire Type | drive 20.5R25 steer 12.00-20ML |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
