Excalibur Equipment, LLC RSC8EX
Contents:
Dimensions
| Length To Fork Face | 9.42 ft in (2871.22 mm) |
| Overall Width | 4.5 ft in (1371.6 mm) |
| Overall Height - Mast Lowered | 7.67 ft in (2337.82 mm) |
| Wheelbase | 6.42 ft in (1956.82 mm) |
| Ground Clearance | 6 in (152.4 mm) |
| Height To Top Of Overhead Guard | 7.42 ft in (2261.62 mm) |
| Max Fork Height | 10.83 ft in (3300.99 mm) |
| Right Angle Stack | 10.5 ft in (3200.4 mm) |
| Turning Radius | 8.83 ft in (2691.39 mm) |
Mast
| Mast Tip Forward | 5 degrees |
| Mast Tip Rear | 9 degrees |
| Max Fork Spread | 45 in (1143 mm) |
| Lower Speed | 79 ft/min (79 -) |
| Load Center | 24 in (609.6 mm) |
| Load Capacity | 8000 lb (3628.74 kg) |
| Lift Speed | 98 ft/min (98 -) |
Engine
| Power | 16 hp (12 kw) |
| Fuel Type | electric |
Operational
| Operating Weight | 14520 lb (6586.2 kg) |
| Tire Type | front 250-15 rear 23x9/10 |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 8 mph (12.9 km/h) |
