Excalibur Equipment, LLC Gregory RSC7EX
Contents:
Dimensions
| Length To Fork Face | 8.5 ft in (2590.8 mm) |
| Overall Width | 3.83 ft in (1167.39 mm) |
| Overall Height - Mast Lowered | 7.33 ft in (2234.19 mm) |
| Wheelbase | 5.83 ft in (1776.99 mm) |
| Ground Clearance | 5 in (127 mm) |
| Height To Top Of Overhead Guard | 7.08 ft in (2157.99 mm) |
| Max Fork Height | 10.83 ft in (3300.99 mm) |
| Right Angle Stack | 9.5 ft in (2895.6 mm) |
| Turning Radius | 8 ft in (2438.4 mm) |
Mast
| Mast Tip Forward | 5 degrees |
| Mast Tip Rear | 9 degrees |
| Max Fork Spread | 45 in (1143 mm) |
| Lower Speed | 79 ft/min (79 -) |
| Load Center | 24 in (609.6 mm) |
| Load Capacity | 7000 lb (3175.15 kg) |
| Lift Speed | 118 ft/min (118 -) |
Engine
| Power | 16 hp (12 kw) |
| Fuel Type | electric |
Operational
| Operating Weight | 10780 lb (4889.8 kg) |
| Tire Type | front 23x9/12 rear 18x7/8 |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 7 mph (11.3 km/h) |
