New Holland 255
Browse All New Holland or Crawler Tractor Models
Contents:
Dimensions
| Length W/ Blade | 19.21 ft in (5855 mm) |
| Width Over Tracks | 9.65 ft in (2940 mm) |
| Height To Top Of Cab | 11.23 ft in (3420 mm) |
| Length Of Track On Ground | 9.76 ft in (2973 mm) |
| Ground Clearance | 1.51 ft in (460 mm) |
| Length W/O Blade | 14.74 ft in (4490 mm) |
Undercarriage
| Track Gauge | 6.8 ft in (2070 mm) |
| Standard Shoe Size | 21.66 in (550 mm) |
| Number Of Shoes Per Side | 41 |
| Number Of Carrier Rollers Per Side | 2 |
| Ground Contact Area | 50692.86 in2 (32.71 m2) |
| Number Of Track Rollers Per Side | 7 |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Engine Model | 6C6TAA 8.3 |
| Net Power | 240 hp (179 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 831.8 lb ft (1127.8 Nm) |
| Displacement | 506.5 cu in (8.3 L) |
| Torque Measured @ | 1400 rpm |
| Aspiration | turbocharged aftercooled |
Operational
| Operating Weight | 58643 lb (26600 kg) |
| Fuel Capacity | 132.1 gal (500 L) |
| Cooling System Fluid Capacity | 17.2 gal (65 L) |
| Engine Oil Capacity | 5.9 gal (22 L) |
| Hydraulic Fluid Capacity | 27.8 gal (105 L) |
| Final Drives Fluid Capacity | 12.2 gal (46 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 amps |
Transmission
| Transmission Type | Full PowerShift, CounterShaft, Constant Mesh |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 6.8 mph (10.9 km/h) |
| Max Speed - Reverse | 7.9 mph (12.6 km/h) |
Hydraulic System
| Pump Type | Gear Type |
| Relief Valve Pressure | 2755.8 psi (19000 kPa) |
| Pump Flow Capacity | 56.1 gal/min (212 L/min) |
Standard Blade
| Width | 12.5 ft in (3800 mm) |
| Height | 59.1 in (1500 mm) |
| Capacity | 9.2 yd3 (7 m3) |
| Blade Angle (Both Directions) | 11 degrees |
| Cutting Depth | 20.9 in (530 mm) |
