Rostselmash Vector 410
Browse All Rostselmash or Combine Models
Contents:
Dimensions
| Overall Length | 53.81 ft in (16400 mm) |
| Width Over Tires | 11.68 ft in (3559 mm) |
| Wheelbase | 12.39 ft in (3775 mm) |
| Height To Top Of Isomount Cab | 13.13 ft in (4000 mm) |
Engine
| Engine Make | 2403 |
| Engine Model | YAMZ-236ND |
| Power | 206.6 hp (154 kw) |
| Aspiration | turbocharged |
Operational
| Operating Weight W/O Attachment | 24361.1 lb (11050 kg) |
| Fuel Capacity | 142.7 gal (540 L) |
Feeding
| Conveyor Width | 252 in (6400 mm) |
| Conveyor Speed | 49 rpm |
Threshing
| Rotor Diameter | 31.5 in (800 mm) |
| Rotor Length | 46.7 in (1184 mm) |
| Rotor Speed - Low | 420 rpm |
| Rotor Speed - High | 945 rpm |
| Concave Area | 1698.9 in2 (1.1 m2) |
Separating
| Separator Type | 4 key straw walker |
| Separator Length | 161.5 in (4100 mm) |
| Separating Area | 7750.1 in2 (5 m2) |
Cleaning System
| Total Cleaning Area | 5564.6 in2 (3.6 m2) |
| Cleaning Fan Speed - Low | 380 rpm |
| Cleaning Fan Speed - High | 1000 rpm |
Grain Handling
| Grain Tank Capacity | 170.3 bu (6000 L) |
| Unloading Speed | 1.2 bu/sec (42 L/sec) |
| Unloading Discharge Height | 10.9 ft in (3.3 m) |
