Rostselmash Niva-Effect
Browse All Rostselmash or Combine Models
Contents:
Dimensions
| Overall Length | 35.83 ft in (10920 mm) |
| Width Over Tires | 13.55 ft in (4130 mm) |
| Wheelbase | 11.62 ft in (3540 mm) |
| Height To Top Of Isomount Cab | 13.03 ft in (3970 mm) |
Engine
| Engine Make | 0 |
| Engine Model | D-260.1 |
| Power | 152.9 hp (114 kw) |
| Aspiration | turbocharged |
Operational
| Operating Weight W/O Attachment | 14632.1 lb (6637 kg) |
| Fuel Capacity | 79.3 gal (300 L) |
Feeding
| Conveyor Width | 210.7 in (5350 mm) |
| Conveyor Speed | 42 rpm |
Threshing
| Rotor Diameter | 23.7 in (600 mm) |
| Rotor Length | 46.7 in (1185 mm) |
| Rotor Speed - Low | 743 rpm |
| Rotor Speed - High | 1260 rpm |
| Concave Area | 1441.6 in2 (1 m2) |
Separating
| Separator Type | 4 key straw walker |
| Separator Length | 142.5 in (3618 mm) |
| Separating Area | 6727.1 in2 (4.4 m2) |
Cleaning System
| Total Cleaning Area | 3751.1 in2 (2.5 m2) |
| Cleaning Fan Speed - Low | 432 rpm |
| Cleaning Fan Speed - High | 723 rpm |
Grain Handling
| Grain Tank Capacity | 85.2 bu (3000 L) |
| Unloading Discharge Height | 8.6 ft in (2.6 m) |
