Tadano ATF30-2L
Browse All Tadano or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 28.22 ft in (8.6 m) |
| Max Height @ Max Raise Angle - No Jib | 93.51 ft in (28.5 m) |
| Number Of Sections | 4 |
| Swing Speed | 2.5 rpm |
Dimensions
| Transport Length | 32.73 ft in (9975 mm) |
| Transport Width | 8.37 ft in (2550 mm) |
| Transport Height | 10.89 ft in (3317 mm) |
| Ground Clearance | 1.56 ft in (475 mm) |
| Width W/ Outriggers Extended | 20.61 ft in (6280 mm) |
| Carrier Length | 27.24 ft in (8300 mm) |
| Upper Structure Tail Swing Radius | 10.18 ft in (3100 mm) |
Carrier Engine
| Make | Tadano |
| Model | OM 906 LA |
| Gross Power | 275 hp (205 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 811.4 lb ft (1100 Nm) |
| Torque Measured @ | 1600 rpm |
Operational
| Number Of Axels | 2 |
| Operating Voltage | 24 V |
| Tire Size | 14.00R25 |
Transmission
| Transmission Type | ZF Powershift 6WG210 |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 1 |
