Tadano ATF50G-3
Browse All Tadano or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 42 ft in (12.81 m) |
| Max Height @ Max Raise Angle - No Jib | 141.08 ft in (43 m) |
| Min Working Radius | 8.2 ft in (2.5 m) |
| Max Working Radius | 118.1 ft in (36 m) |
| Max Elevating Angle | 83 degrees |
| Number Of Sections | 5 |
| Max Lift Capacity | 110000 lb (49895.17 kg) |
| Swing Speed | 2.21 rpm |
Dimensions
| Transport Length | 37.31 ft in (11370 mm) |
| Transport Width | 8.37 ft in (2550 mm) |
| Transport Height | 12.21 ft in (3720 mm) |
| Width W/ Outriggers Extended | 20.67 ft in (6300 mm) |
| Carrier Length | 30.81 ft in (9390 mm) |
| Upper Structure Tail Swing Radius | 11.32 ft in (3450 mm) |
Carrier Engine
| Make | Tadano |
| Model | OM 926 LA |
| Gross Power | 326 hp (243.1 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 958.9 lb ft (1300 Nm) |
| Torque Measured @ | 1600 rpm |
| Displacement | 439.4 cu in (7.2 L) |
Operational
| Operating Weight | 79370 lb (36001.7 kg) |
| Number Of Axels | 3 |
| Carrier Fuel Capacity | 92.5 gal (350 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 amps |
| Tire Size | 14.00R25 |
Transmission
| Transmission Type | full automatic |
| Number Of Forward Gears | 12 |
| Number Of Reverse Gears | 2 |
| Max Speed - Forward | 52.2 mph (84.1 km/h) |
| Max Speed - Reverse | 4.3 mph (7 km/h) |
