XCMG LW620G
Browse All XCMG or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 10.18 ft in (3100 mm) |
| Bucket Capacity - Heaped | 4.32 yd3 (3.3 m3) |
| Breakout Force | _ - (196 kN) |
Dimensions
| Ground Clearance | 1.48 ft in (450 mm) |
| Length With Bucket On Ground | 28.2 ft in (8593 mm) |
| Height To Top Of Cab | 11.27 ft in (3435 mm) |
| Wheelbase | 11.16 ft in (3400 mm) |
| Reach At Max Lift And Dump | 4.11 ft in (1250 mm) |
Engine
| Engine Model | Cat |
| Net Power | 233.4 hp (174 kw) |
Operational
| Operating Weight | 45194.8 lb (20500 kg) |
| Fuel Capacity | 66.1 gal (250 L) |
| Static Tipping Weight | 34943.3 lb (15850 kg) |
| Tire Size | 23.5-25-16PR |
Transmission
| Transmission Type | countershaft powershift |
