Gehl AWS680
Browse All Gehl or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 8.73 ft in (2660 mm) |
| Bucket Capacity - Heaped | 2.36 yd3 (1.8 m3) |
| Breakout Force | 9217 lb (41 kN) |
Dimensions
| Ground Clearance | 1.05 ft in (320 mm) |
| Length With Bucket On Ground | 18.38 ft in (5600 mm) |
| Width Over Tires | 6.01 ft in (1830 mm) |
| Height To Top Of Cab | 8.9 ft in (2710 mm) |
| Wheelbase | 6.73 ft in (2050 mm) |
| Hinge Pin - Max Height | 11.16 ft in (3400 mm) |
| Reach At Max Lift And Dump | 1.97 ft in (600 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2349 |
| Engine Model | BF4M 2011 |
| Gross Power | 75 hp (56 kw) |
| Power Measured @ | 2300 rpm |
| Max Torque | 199 lb ft (269.9 Nm) |
| Displacement | 190 cu in (3.2 L) |
| Torque Measured @ | 1600 rpm |
Operational
| Operating Weight | 12015 lb (5450 kg) |
| Fuel Capacity | 21.2 gal (80 L) |
| Hydraulic System Fluid Capacity | 22.5 gal (85 L) |
| Static Tipping Weight | 8730 lb (3959.9 kg) |
| Turning Radius | 13.1 ft in (3980 mm) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 amps |
| Rear Axle Oscillation | 18 degrees |
Transmission
| Max Speed - Forward | 12.4 mph (20 km/h) |
Hydraulic System
| Relief Valve Setting | 3400 psi (23442.2 kPa) |
| Pump Flow Capacity | 18.5 gal/min (70.1 L/min) |
| Pump Type | gear |
