Gehl AWS480
Browse All Gehl or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 8.21 ft in (2500 mm) |
| Bucket Capacity - Heaped | 1.84 yd3 (1.4 m3) |
| Breakout Force | 7868 lb (7868 -) |
Dimensions
| Ground Clearance | 1.05 ft in (320 mm) |
| Length With Bucket On Ground | 16.67 ft in (5080 mm) |
| Width Over Tires | 5.58 ft in (1700 mm) |
| Height To Top Of Cab | 8.24 ft in (2510 mm) |
| Wheelbase | 6.3 ft in (1920 mm) |
| Hinge Pin - Max Height | 10.67 ft in (3250 mm) |
| Reach At Max Lift And Dump | 2.3 ft in (700 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2349 |
| Engine Model | F4M 2011 |
| Gross Power | 59 hp (44 kw) |
| Power Measured @ | 2400 rpm |
| Max Torque | 144 lb ft (195.3 Nm) |
| Displacement | 190 cu in (3.2 L) |
| Torque Measured @ | 1700 rpm |
Operational
| Operating Weight | 9921 lb (4500.1 kg) |
| Fuel Capacity | 21.2 gal (80 L) |
| Hydraulic System Fluid Capacity | 18.5 gal (70 L) |
| Static Tipping Weight | 7496 lb (3400.2 kg) |
| Turning Radius | 11.4 ft in (3450 mm) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 amps |
| Rear Axle Oscillation | 18 degrees |
Transmission
| Max Speed - Forward | 12.4 mph (20 km/h) |
Hydraulic System
| Relief Valve Setting | 3046 psi (21001.5 kPa) |
| Pump Flow Capacity | 17.5 gal/min (66.3 L/min) |
| Pump Type | gear |
