| Ground Clearance | 1.3 ft in (0.4 m) |
| Machine Width - 12-16.5 10pr Tires | 5.4 ft in (1.65 m) |
| Machine Width - Flexport 33 6 11 Tires | 5.2 ft in (1.59 m) |
| Machine Width - Flotation 33-15.5 16.5 Tires | 5.6 ft in (1.71 m) |
| Maximum Dump Height | 8 ft in (2.44 m) |
| Maximum Fork Height | 10.3 ft in (3.14 m) |
| Maximum Reach | 5.4 ft in (1.65 m) |
| Overall Length - With Bucket | 15.9 ft in (4.85 m) |
| Overall Length - With Forks | 17.4 ft in (5.31 m) |
| Reach - Ground Level | 3.7 ft in (1.13 m) |
| Reach At Maximum Dump Height | 2.9 ft in (0.89 m) |
| Steering Angle - Left/Right | 80 |
| Tire Gauge | 4.3 ft in (1.32 m) |
| Turning Radius - Inside Tire | 5.4 ft in (1.65 m) |
| Turning Radius - Over Bucket | 13.2 ft in (4.03 m) |
| Wheel Base | 5.9 ft in (1.8 m) |
| Articulation Angle | 40 |
| Width - Over Bucket | 5.8 ft in (1.77 m) |
| Cab Height | 8.2 ft in (2.5 m) |
| Departure Angle | 30 |
| Dig Depth | 8 in (203.2 mm) |
| Dump Angle At Maximum Height | 40 |
| Fork Depth Above Ground | 2 in (50.8 mm) |
| Fork Height At Maximum Reach | 4.7 ft in (1.44 m) |
| Fork Reach At Maximum Height | 2.5 ft in (0.77 m) |
| Hinge Pin At Maximum Height | 10.6 ft in (3.24 m) |
| Load Over Height | 9.6 ft in (2.93 m) |
| Breakout Force | 5171 lb (2345.6 kg) |
| Rated Bucket Capacity | 0.8 yd3 (0.7 m3) |
| Tire Size | 33 15.5-16.5, 12PR |
| Standard - Operating Weight | 9150 lb (4150.4 kg) |
| Standard - Rated Operating Load At Full Turn - Bucket | 1950 lb (884.6 kg) |
| Standard - Straight Tipping Load, Bucket | 4650 lb (2109.3 kg) |
| Standard - Full Turn Static Tipping Load, Bucket | 3900 lb (1769.1 kg) |
| Standard - Rackback, Transport Position | 52 |
| Standard - Rated Operating Load At Full Turn - Forks (En 474-3:2006, Firm And Level Ground, 500 Mm (20 In) Load Center) (80% Of Ftstl) | 2500 lb (1134 kg) |
| Standard - Rated Operating Load At Full Turn - Forks (En 474-3:2006, Rough Terrain, 500 Mm (20 In) Load Center) (60% Of Ftstl) | 1900 lb (861.9 kg) |
| With Additional Counterweight - Operating Weight | 9500 lb (4309.2 kg) |
| With Additional Counterweight - Rated Operating Load At Full Turn - Bucket | 2100 lb (952.6 kg) |
| With Additional Counterweight - Straight Tipping Load - Bucket | 5000 lb (2268 kg) |
| With Additional Counterweight - Full Turn Static Tipping Load - Bucket | 4200 lb (1905.1 kg) |
| With Additional Counterweight - Rackback - Transport Position | 52 |
| With Additional Counterweight - Rated Operating Load At Full Turn - Forks (En 474-3:2006, Firm And Level Ground, 500 Mm (20 In) Load Center) (80% Of Ftstl) | 2700 lb (1224.7 kg) |
| With Additional Counterweight - Rated Operating Load At Full Turn - Forks (En 474-3:2006, Rough Terrain, 500 Mm (20 In) Load Center) (60% Of Ftstl) | 2000 lb (907.2 kg) |
| Note | Based on ISO 7546: 1983 and rated operating loads at full turn and without additional counterweight |
| General Purpose - Bucket Type | General Purpose |
| General Purpose - Rated Capacity | 0.8 yd3 (0.7 m3) |
| General Purpose - Dump Height | 96 in (2438.4 mm) |
| General Purpose - Maximum Material Density | 2437 lb/yd |
| General Purpose - Bucket Width | 70 in (1778 mm) |
| Light Material - Bucket Type | Light Material |
| Light Material - Rated Capacity | 1.3 yd3 (1 m3) |
| Light Material - Dump Height | 91 in (2311.4 mm) |
| Light Material - Maximum Material Density | 1423 lb/yd |
| Light Material - Bucket Width | 74 in (1879.6 mm) |
