Case 821CXR
Browse All Case or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.75 ft in (2970 mm) |
| Bucket Capacity - Heaped | 3.51 yd3 (2.68 m3) |
| Bucket Capacity - Struck | 3.04 yd3 (2.32 m3) |
| Bucket Width | 9.09 ft in (2770 mm) |
| Breakout Force | 36391 lb (36391 -) |
Dimensions
| Ground Clearance | 1.32 ft in (401 mm) |
| Length With Bucket On Ground | 24.51 ft in (7470 mm) |
| Width Over Tires | 8.86 ft in (2700 mm) |
| Height To Top Of Cab | 10.93 ft in (3330 mm) |
| Wheelbase | 10.5 ft in (3200 mm) |
| Hinge Pin - Max Height | 12.96 ft in (3950 mm) |
| Reach At Max Lift And Dump | 3.65 ft in (1110 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2239 |
| Engine Model | 6TAA-8304 |
| Net Power | 186 hp (138.8 kw) |
| Gross Power | 204 hp (152.2 kw) |
| Power Measured @ | 2000 rpm |
| Max Torque | 671 lb ft (909.8 Nm) |
| Displacement | 504 cu in (8.3 L) |
| Torque Measured @ | 1400 rpm |
| Aspiration | turbocharged and air to air cooled |
| Torque Rise | 51 % |
Operational
| Operating Weight | 37901 lb (17191.7 kg) |
| Fuel Capacity | 70.8 gal (268 L) |
| Hydraulic System Fluid Capacity | 46 gal (174 L) |
| Engine Oil Fluid Capacity | 5.6 gal (21 L) |
| Cooling System Fluid Capacity | 8.5 gal (32 L) |
| Transmission Fluid Capacity | 3.2 gal (12 L) |
| Front Axle/Diff Fluid Capacity | 8.8 gal (33 L) |
| Rear Axle/Diff Fluid Capacity | 7.1 gal (26.5 L) |
| Static Tipping Weight | 30082.1 lb (13645 kg) |
| Turning Radius | 18.9 ft in (5750 mm) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 65 amps |
| Rear Axle Oscillation | 24 degrees |
| Tire Size | 23.5-25 L3 |
Transmission
| Transmission Type | 4F/3R proportional w/ electronic control module torque sensing autoshift/manual shift and modulation |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 23.5 mph (37.9 km/h) |
| Max Speed - Reverse | 16.6 mph (26.8 km/h) |
Hydraulic System
| Relief Valve Setting | 2813.8 psi (19400 kPa) |
| Pump Flow Capacity | 50 gal/min (189 L/min) |
| Raise Time | 5.9 sec |
| Dump Time | 1.6 sec |
| Lower Time | 4.3 sec |
| Pump Type | dual, vane-type tandem |
