Case 321E
Browse All Case or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 8.65 ft in (2635 mm) |
| Bucket Capacity - Heaped | 1.44 yd3 (1.11 m3) |
| Bucket Capacity - Struck | 1.18 yd3 (0.91 m3) |
| Bucket Width | 6.89 ft in (2100 mm) |
| Breakout Force | 11241 lb (50 kN) |
Dimensions
| Ground Clearance | 1.08 ft in (330 mm) |
| Length With Bucket On Ground | 18.88 ft in (5755 mm) |
| Width Over Tires | 6.49 ft in (1978 mm) |
| Height To Top Of Cab | 9.14 ft in (2785 mm) |
| Wheelbase | 7.71 ft in (2350 mm) |
| Hinge Pin - Max Height | 11.35 ft in (3459 mm) |
| Reach At Max Lift And Dump | 2.92 ft in (888 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2349 |
| Engine Model | BF4M2011 tier 2 certified |
| Net Power | 72 hp (53.5 kw) |
| Gross Power | 75 hp (56 kw) |
| Power Measured @ | 2300 rpm |
| Max Torque | 195 lb ft (265 Nm) |
| Displacement | 190 cu in (3.2 L) |
| Torque Measured @ | 1600 rpm |
| Torque Rise | 9 % |
Operational
| Operating Weight | 12676 lb (5896 kg) |
| Fuel Capacity | 26.4 gal (100 L) |
| Hydraulic System Fluid Capacity | 19.5 gal (74 L) |
| Engine Oil Fluid Capacity | 2.7 gal (10 L) |
| Front Axle/Diff Fluid Capacity | 2.2 gal (8 L) |
| Rear Axle/Diff Fluid Capacity | 2.2 gal (8 L) |
| Static Tipping Weight | 9744 lb (4420 kg) |
| Turning Radius | 13.6 ft in (4132 mm) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 amps |
| Rear Axle Oscillation | 24 degrees |
| Tire Size | 405/70 R20 |
Transmission
| Transmission Type | Hydrostatic |
| Number Of Forward Gears | 2 |
| Number Of Reverse Gears | 2 |
| Max Speed - Forward | 12.4 mph (20 km/h) |
| Max Speed - Reverse | 12.4 mph (20 km/h) |
Hydraulic System
| Relief Valve Setting | 3626 psi (25000 kPa) |
| Pump Flow Capacity | 19.3 gal/min (73 L/min) |
| Raise Time | 6 sec |
| Dump Time | 1 sec |
| Lower Time | 3 sec |
| Pump Type | open centered pressure/flow compensated |
