Ingersoll Rand SD122D
Browse All Ingersoll Rand or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 19.35 in (5895 mm) |
| Overall Width | 7.5 ft in (2286 mm) |
| Height To Top Of Cab | 10.15 ft in (3091 mm) |
| Wheelbase | 10.18 in (3100 mm) |
Engine
| Engine Make | 2347 |
| Engine Model | QSB5.9-3OT |
| Net Power | 156 hp (116.4 kw) |
| Aspiration | turbocharged |
Operational
| Operating Weight | 26460 lb (12002.1 kg) |
| Fuel Capacity | 68 gal (257.5 L) |
| Hydraulic System Fluid Capacity | 22 gal (83.3 L) |
| Max Speed | 7.6 mph (12.1 km/h) |
| Tires *If Applicable | 23.1x26 8PR R3 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 95 amps |
Drum
| Drum Width | 84.1 in (2134 mm) |
| Drum Diameter | 59.1 in (1499 mm) |
| Vibration Frequency 1 | 30.9 Hz |
| Nominal Amplitude - High | 0.1 in (1.9 mm) |
| Vibration Frequency 2 | 33.8 Hz |
| Nominal Amplitude - Low | 0.1 in (1.2 mm) |
| Centrifugal Force - High | 63171.4 lb (281 kN) |
| Centrifugal Force - Low | 46310.7 lb (206 kN) |
