Hamm HD754
Browse All Hamm or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 14.24 in (4340 mm) |
| Height To Top Of Cab | 9.55 ft in (2910 mm) |
Engine
| Engine Make | 2349 |
| Engine Model | BF4M1011F |
| Gross Power | 75.4 hp (56.2 kw) |
| Power Measured @ | 2500 rpm |
Operational
| Operating Weight | 17857.5 lb (8100 kg) |
| Fuel Capacity | 34.4 gal (130 L) |
Drum
| Drum Width | 66.2 in (1680 mm) |
| Vibration Frequency 1 | 50 Hz |
| Nominal Amplitude - High | 0.1 in (0.6 mm) |
| Nominal Amplitude - Low | 0.1 in (0.4 mm) |
| Centrifugal Force - High | 14837.4 lb (66 kN) |
| Centrifugal Force - Low | 14387.8 lb (64 kN) |
