Bomag BW 124 PDH-40
Browse All Bomag or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 131.9 in (3350.26 mm) |
| Overall Width | 4.3 ft in (1310.65 mm) |
| Height To Top Of Cab | 8.18 ft in (2491.74 mm) |
| Wheelbase | 71.1 in (1805.94 mm) |
| Ground Clearance | 12.6 in (320.05 mm) |
| Operating Width | 3.94 ft in (1198.88 mm) |
Steering System
| System | Oscillatory Articulation |
| Steering Method | Hydrostatic |
Engine
| Fuel | Diesel |
| Emissions Level | 3a/4i |
| Number Of Cylinders | 3 |
| Cooling Method | Air - oil |
| Engine Make | Deutz |
| Engine Model | D2011 L03i |
| Gross Power | 44.3 hp (33.1 kw) |
| Power Measured @ | 2500 rpm |
Operational
| Max. Gradeability Without/With Vibratory | 55 % |
| Operating Weight | 7386 lb (3350.3 kg) |
| Fuel Capacity | 15.9 gal (60.2 L) |
| Max Speed | 5.6 mph (9.1 km/h) |
| Tires *If Applicable | 9.5-24 |
| Operating Voltage | 12 V |
Drum
| Drum Width | 47.3 in (1200 mm) |
| Drum Diameter | 37.8 in (960 mm) |
| Number Of Pads | 70 |
| Static Linear Load | 74.5 lb/in (13.3 kg/cm) |
| Pad Height | 2.2 in (55.9 mm) |
| Vibration Frequency 1 | 41 Hz |
| Pad Surface Area | 12.6 in2 (81.3 cm2) |
| Nominal Amplitude - High | 0.1 in (1.8 mm) |
| Vibration Frequency 2 | 40 Hz |
| Centrifugal Force - High | 19109 lb (85.1 kN) |
Weights
| Grossweight | 8598 lb (3900 kg) |
| Loaded Weight | 3638 lb (1650.2 kg) |
Brakes
| Parking Brake | Hydromec |
| Service Brake | Hydrostatic |
