Ingersoll Rand SD25F
Browse All Ingersoll Rand or Vibratory Compactor Models
Contents:
Dimensions
| Width Over Tires | 4.12 ft in (1254 mm) |
| Height To Top Of Cab | 7.53 ft in (2294 mm) |
| Wheelbase | 5.49 in (1673 mm) |
| Ground Clearance | 10.67 in (271 mm) |
| Overall Length W/ Blade | 10.42 ft in (3175 mm) |
Drum
| Drum Diameter | 30.99 in (787 mm) |
| Vibration Frequency 1 | 36.71 Hz |
| Number Of Pads | 45 |
| Drum Width | 42.01 in (1067 mm) |
| Nominal Amplitude - High | 0.06 in (1.4 mm) |
| Centrifugal Force - High | 12499.38 lb (55.6 kN) |
| Pad Height | 2.52 in (64 mm) |
| Pad Surface Area | 8.5 in2 (5483.86 cm2) |
Engine
| Engine Make | 2334 |
| Engine Model | V2203-M Tier II |
| Net Power | 44 hp (32.9 kw) |
Operational
| Operating Weight | 5919.5 lb (2685 kg) |
| Fuel Capacity | 11.9 gal (45 L) |
| Hydraulic System Fluid Capacity | 15.1 gal (57 L) |
| Max Speed | 5.6 mph (9 km/h) |
| Tires | 8x16-6PR R1 Lug |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 amps |
