Merlo P 80.9 HM
Browse All Merlo or Telescopic Forklift Models
Contents:
Dimensions
| Length To Fork Face | 18.84 ft in (5740 mm) |
| Ground Clearance | 1.48 ft in (450 mm) |
| Width Over Tires | 7.88 ft in (2400 mm) |
| Overall Height | 9.36 ft in (2850 mm) |
| Wheelbase | 10.63 ft in (3240 mm) |
| Turning Radius Outside Tires | 14.11 ft in (4300 mm) |
Lift
| Max Lift Height | 29.86 ft in (9100 mm) |
| Max Forward Reach | 16.41 ft in (5000 mm) |
| Max Load At Max Reach | 6613.87 lb (3000 kg) |
| Max Load At Max Height | 11023.12 lb (5000 kg) |
| Max Lift Capacity | 17636.98 lb (8000 kg) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Gross Power | 145 hp (108.2 kw) |
| Power Measured @ | 2300 rpm |
| Displacement | 244.1 cu in (4 L) |
| Aspiration | turbocharged intercooler |
Operational
| Operating Weight | 33289.8 lb (15100 kg) |
| Fuel Capacity | 48.9 gal (185 L) |
| Hydraulic System Fluid Capacity | 47.6 gal (180 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 90 amps |
| Tire Size | 17.5-25 22PR |
Transmission
| Transmission Type | hydrostatic |
| Number Of Forward Gears | 2 |
| Number Of Reverse Gears | 2 |
| Max Speed - Forward | 24.9 mph (40 km/h) |
| Max Speed - Reverse | 24.9 mph (40 km/h) |
Hydraulic
| Pump Type | load sensing |
| Pump Flow Capacity | 36.5 gal/min (138 L/min) |
| Relief Valve Pressure | 3335.9 psi (23000 kPa) |
