Haulotte HTL11532
Browse All Haulotte or Telescopic Forklift Models
Contents:
Dimensions
| Ground Clearance | 1.64 ft in (497.84 mm) |
| Overall Height | 8.6 ft in (2621.29 mm) |
| Wheelbase | 9.6 ft in (2926.08 mm) |
| Max Fork Height | 32.1 ft in (9784.08 mm) |
| Approach Angle | 29 degrees |
| Cab Width | 3.2 ft in (0.98 m) |
| Height | 103.2 in (2621.29 mm) |
| Overall Track Width | 6.7 ft in (2042.16 mm) |
| Reach At Maximum Fork Height | 1 ft in (304.8 mm) |
| Turning Radius Outside Tires | 14.9 ft in (4541.53 mm) |
| Width | 8 ft in (2438.4 mm) |
| Overall Length | 20.7 ft in (6309.36 mm) |
Lift
| Max Forward Reach | 18.8 ft in (5730.24 mm) |
| Max Load At Max Height | 11466 lb (5200.9 kg) |
| Max Load At Max Reach | 7717 lb (3500.38 kg) |
| Max Lift Capacity | 11466 lb (5200.9 kg) |
Engine
| Emission Tier Level | TIER IV INTERIM |
| Engine Model | PERKINS TIER IV |
| Gross Power | 111.4 hp (83 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 332 lb ft (450 Nm) |
| Torque Measured @ | 1400 rpm |
| Displacement | 207 cu in (3.4 L) |
Operational
| Operating Weight | 23836 lb (10811.9 kg) |
| Fuel Capacity | 34.3 gal (129.9 L) |
| Engine Oil Capacity | 2.5 gal (9.5 L) |
| Tire Size | 400/80-24 |
Transmission
| Transmission Type | Hydrostatic |
