John Deere 325
Browse All John Deere or Skid Steer Loader Models
Contents:
Dimensions
| Length With Bucket | 11.55 ft in (3518 mm) |
| Width Over Tires | 6.15 ft in (1872 mm) |
| Ground Clearance | 9 in (229 mm) |
| Height To Top Of Cab | 6.75 ft in (2055 mm) |
| Wheelbase | 3.97 ft in (1209 mm) |
| Length W/O Bucket | 9.63 ft in (2934 mm) |
| Clearance At Max Lift And Dump | 8.34 ft in (2540 mm) |
| Reach At Max Lift And Dump | 34.02 in (864 mm) |
| Turning Radius From Center - Inc Bucket | 83.71 in (2126 mm) |
Engine
| Number Of Cylinders | 5 |
| Engine Make | 2240 |
| Engine Model | 5030T |
| Gross Power | 76 hp (56.7 kw) |
| Net Power | 70 hp (52.2 kw) |
| Power Measured @ | 2800 rpm |
| Aspiration | Turbocharged |
| Displacement | 186 cu in (3.1 L) |
Operational
| Operational Weight | 8390 lb (3806 kg) |
| Fuel Capacity | 24.1 gal (91 L) |
| Max Speed | 11 mph (17.7 km/h) |
| Tire Size | 12x16.5 8 PR SKS |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 70 amps |
Loader
| Breakout Force | 7500 lb (3402 kg) |
| Operating Load Rating | 2500 lb (1134 kg) |
| Tipping Angle | 5000 degrees |
| Bucket Capacity | 0.7 yd3 (0.5 m3) |
Hydraulic
| Pump Flow Capacity | 22 gal/min (83 L/min) |
| Relief Valve Pressure | 3100 psi (21373.8 kPa) |
