Haulotte Compact 2668 RT
Browse All Haulotte or Scissor Lift Models
Contents:
Dimensions
| Overall Length | 10.5 in (266.7 mm) |
| Wheelbase | 6 ft in (1828.8 mm) |
| Overall Width | 5.1 ft in (1554.48 mm) |
| Height W/ Rails | 8 ft in (2438.4 mm) |
| Ground Clearance | 11 in (279.4 mm) |
| Height W/O Rails | 4.92 ft in (1499.62 mm) |
| Turning Radius | 11.6 ft in (3535.68 mm) |
| Gradeability | 40 % |
Platform
| Max Platform Height | 27.2 ft in (8290.56 mm) |
| Deck Extension | 47 in (1193.8 mm) |
| Max Working Height | 33.21 ft in (10119.36 mm) |
| Max Platform Weight Capacity | 1250 lb (567 kg) |
| Platform Inner Length | 96 in (2438.4 mm) |
| Platform Inner Width | 57 in (1447.8 mm) |
| Lower Time | 46 sec |
| Lift Time | 35 sec |
Engine
| Engine Make | 2349 |
| Gross Power | 24.8 hp (18.5 kw) |
| Fuel Type | Diesel |
Operational
| Operating Weight | 7762 lb (3520.8 kg) |
| Fuel Capacity | 8 gal (30.3 L) |
| Hydraulic System Fluid Capacity | 20 gal (75.8 L) |
| Max Speed | 3.4 mph (5.5 km/h) |
| Tire Size | 26x12-16.5 |
| Tire Fill/Type | Foam |
