Grove S3268E
Browse All Grove or Scissor Lift Models
Contents:
Dimensions
| Overall Length | 9.91 in (3020 mm) |
| Wheelbase | 7.52 ft in (2290 mm) |
| Overall Width | 5.68 ft in (1730 mm) |
| Height W/ Rails | 8.17 ft in (2490 mm) |
| Ground Clearance | 5.5 in (139.7 mm) |
| Height W/O Rails | 4.17 ft in (1270 mm) |
Platform
| Max Platform Height | 31.99 ft in (9750 mm) |
| Deck Extension | 35.83 in (910 mm) |
| Height Of Rails | 4.01 ft in (1220 mm) |
| Max Working Height | 38 ft in (11580 mm) |
| Lower Time | 60 sec |
| Lift Time | 60 sec |
| Platform Inner Length | 112.21 in (2850 mm) |
| Platform Inner Width | 59.85 in (1520 mm) |
| Max Platform Weight Capacity | 1000.9 lb (454 kg) |
Engine
| System Voltage | 24 V |
| Number Of Batteries | 4 |
| Battery Amp Hours | 350 |
| Charger Amps | 36 amps |
Operational
| Operating Weight | 7121 lb (3230 kg) |
| Max Speed | 2.5 mph (4.1 km/h) |
| Tire Size | 16x5 |
| Tire Fill/Type | Solid non-marking |
