Link-Belt HSP-8022
Browse All Link-Belt or Rough Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 28.75 ft in (8.76 m) |
| Max Height @ Max Raise Angle - No Jib | 70.25 ft in (21.41 m) |
| Max Elevating Angle | 80 degrees |
| Number Of Sections | 3 |
| Swing Speed | 3 rpm |
Dimensions
| Transport Length | 39.67 ft in (12090 mm) |
| Transport Width | 8.73 ft in (2660 mm) |
| Transport Height | 11.23 ft in (3420 mm) |
| Wheelbase | 121.26 in (3080 mm) |
| Width W/ Outriggers Extended | 18.44 ft in (5620 mm) |
| Carrier/Base Length | 21.99 ft in (6.7 m) |
| Upper Structure Tail Swing Radius | 15.85 ft in (4830 mm) |
Engine
| Number Of Cylinders | 8 |
| Engine Model | GM 8.2N |
| Gross Power | 130 hp (97 kw) |
| Power Measured @ | 2800 rpm |
| Max Torque | 330 lb ft (447.5 Nm) |
| Displacement | 500 cu in (8.2 L) |
| Bore | 4.3 in (108 mm) |
| Stroke | 4.5 in (112 mm) |
| Crankcase Capacity | 11.4 L |
Operational
| Operating Weight | 45988.5 lb (20860 kg) |
| Fuel Capacity | 75 gal (284 L) |
| Hydraulic System Fluid Capacity | 100 gal (378.6 L) |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 80 amps |
| Tire Size | 20.5 x 25 (20 PR) |
Transmission
| Transmission Type | Allison |
| Number Of Forward Gears | 8 |
| Number Of Reverse Gears | 2 |
| Max Speed - Forward | 19.4 mph (31.2 km/h) |
Hydraulic
| Maximum Operating Pressure | 2800 psi (19305.4 kPa) |
