Link-Belt HSP-8010
Browse All Link-Belt or Rough Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 35.01 ft in (10.67 m) |
| Max Height @ Max Raise Angle - No Jib | 85.01 ft in (25.91 m) |
| Max Elevating Angle | 78 degrees |
| Number Of Sections | 3 |
| Swing Speed | 2.46 rpm |
Dimensions
| Transport Length | 46.1 ft in (14050 mm) |
| Transport Width | 8.54 ft in (2600 mm) |
| Transport Height | 12.57 ft in (3830 mm) |
| Wheelbase | 151.19 in (3840 mm) |
| Width W/ Outriggers Extended | 24.02 ft in (7320 mm) |
| Carrier/Base Length | 27.37 ft in (8.34 m) |
| Upper Structure Tail Swing Radius | 25 ft in (7620 mm) |
Engine
| Number Of Cylinders | 6 |
| Gross Power | 205 hp (152.9 kw) |
| Power Measured @ | 2700 rpm |
| Max Torque | 445 lb ft (603.4 Nm) |
| Displacement | 318 cu in (5.3 L) |
| Bore | 3.9 in (98.5 mm) |
| Stroke | 4.5 in (114.3 mm) |
| Crankcase Capacity | 17.41 L |
Operational
| Fuel Capacity | 100 gal (378.6 L) |
Transmission
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 2 |
Hydraulic
| Maximum Operating Pressure | 2900 psi (19994.8 kPa) |
