Mauldin MG618
Browse All Mauldin or Motor Grader Models
Contents:
Dimensions
| Overall Length | 23 ft in (7010.4 mm) |
| Width Over Tires | 7.41 ft in (2258.57 mm) |
| Wheelbase | 16.5 ft in (5029.2 mm) |
| Tandem Axle Wheelbase | 3.71 ft in (1130.81 mm) |
| Blade Base | 6.79 ft in (2069.6 mm) |
| Height To Top Of Isomount Cab | 9.08 ft in (2767.59 mm) |
Engine
| Engine Make | 2349 |
| Engine Model | 2012 |
| Max Power | 133 hp (99.2 kw) |
| Net Torque Gears 1-2 | 363.3 lb ft (492.6 Nm) |
| Displacement | 246.6 cu in (4.1 L) |
| Aspiration | turbocharged and aftercooled |
Operational
| Std Operation Weight - Front Axle | 5600 lb (2540.2 kg) |
| Hydraulic System Fluid Capacity | 20 gal (75.8 L) |
| Std Operation Weight - Rear Axle | 12990 lb (5892.2 kg) |
| Std Operation Weight - Total | 18590 lb (8432.3 kg) |
| Fuel Capacity | 40 gal (151.5 L) |
| Tire Size | 15-19.5 |
| Operating Voltage | 12 V |
Steering
| Articulation Angle | 32 degrees |
| Turning Radius | 18 ft in (5.5 m) |
Transmission
| Transmission Type | hydrostatic |
| Number Of Gears - Forward | 2 |
| Number Of Gears - Reverse | 2 |
| Max Speed - Forward | 17 mph (27.4 km/h) |
| Max Speed - Reverse | 17 mph (27.4 km/h) |
Front Axle
| Wheel Lean | 20 degrees |
| Oscillation - Total | 30 degrees |
Moldboard
| Moldboard Width | 10 ft in (3048 mm) |
| Moldboard Height | 19 in (482.6 mm) |
Circle
| Max Reach Outside Tires - Left | 36 in (914.4 mm) |
| Max Reach Outside Tires - Right | 36 in (914.4 mm) |
| Max Lift Above Ground | 13.8 in (349.3 mm) |
| Blade Tip Angle - Front | 45 degrees |
| Blade Tip Angle - Rear | 45 degrees |
