Hyundai R170W-7
Browse All Hyundai or Mobile Excavator Models
Contents:
Boom/Stick Option (Mex) 1
| Shipping Length Of Unit | 28.25 ft in (8610 mm) |
| Shipping Height Of Unit | 9.98 ft in (3040 mm) |
| Max Cutting Height | 29.5 ft in (8990 mm) |
| Max Loading Height | 20.84 ft in (6350 mm) |
| Max Reach Along Ground | 27.83 ft in (8480 mm) |
| Max Vertical Wall Dig Depth | 16.05 ft in (4890 mm) |
| Max Digging Depth | 17.79 ft in (5420 mm) |
| Boom/Stick Option (Mex) 1 | Monoboom 5100mm / stick 2200mm |
Boom/Stick Option (Mex) 2
| Shipping Length Of Unit | 28.65 ft in (8730 mm) |
| Shipping Height Of Unit | 9.75 ft in (2970 mm) |
| Max Cutting Height | 29.89 ft in (9110 mm) |
| Max Loading Height | 21.26 ft in (6480 mm) |
| Max Reach Along Ground | 28.94 ft in (8820 mm) |
| Max Vertical Wall Dig Depth | 17.2 ft in (5240 mm) |
| Max Digging Depth | 19.1 ft in (5820 mm) |
| Boom/Stick Option (Mex) 2 | Monoboom 5100mm / stick 2600mm |
Boom/Stick Option (Mex) 3
| Shipping Height Of Unit | 10.31 ft in (3140 mm) |
| Shipping Length Of Unit | 28.78 ft in (8770 mm) |
| Max Cutting Height | 30.25 ft in (9220 mm) |
| Max Loading Height | 21.72 ft in (6620 mm) |
| Max Reach Along Ground | 30.35 ft in (9250 mm) |
| Max Vertical Wall Dig Depth | 18.18 ft in (5540 mm) |
| Max Digging Depth | 20.74 ft in (6320 mm) |
| Boom/Stick Option (Mex) 3 | Monoboom 5100mm / stick 3100mm |
Boom/Stick Option (Mex) 4
| Shipping Height Of Unit | 10.34 ft in (3150 mm) |
| Shipping Length Of Unit | 28.22 ft in (8600 mm) |
| Max Cutting Height | 31.63 ft in (9640 mm) |
| Max Loading Height | 22.74 ft in (6930 mm) |
| Max Reach Along Ground | 27.47 ft in (8370 mm) |
| Max Vertical Wall Dig Depth | 14.54 ft in (4430 mm) |
| Max Digging Depth | 17.13 ft in (5220 mm) |
| Boom/Stick Option (Mex) 4 | Articulated Boom 5100mm / Stick 2200mm |
Dimensions
| Wheelbase | 8.54 ft in (2600 mm) |
| Tail Swing Radius | 8.14 ft in (2480 mm) |
| Overall Width | 8.21 in (2500 mm) |
| Ground Clearance | 1.24 ft in (375 mm) |
| Overall Width - Outriggers Down | 12.09 ft in (3684 mm) |
| Height To Top Of Cab | 10.34 ft in (3150 mm) |
| Upper Structure Clearance | 4.17 ft in (1270 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2251 |
| Engine Model | S6S-DT |
| Gross Power | 126 hp (94 kw) |
| Net Power | 116 hp (86.6 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 305 cu in (5 L) |
| Torque Measured @ | 1500 rpm |
| Net Torque | 307 lb ft (416.3 Nm) |
| Aspiration | turbocharged |
Operational
| Fuel Capacity | 68.7 gal (260 L) |
| Operating Weight | 35714.9 lb (16200 kg) |
| Cooling System Fluid Capacity | 8 gal (30 L) |
| Engine Oil Capacity | 4.4 gal (16.5 L) |
| Front Diff Fluid Capacity | 3.7 gal (14 L) |
| Rear Diff Fluid Capacity | 3.7 gal (14 L) |
| Hydraulic System Fluid Capacity | 63.5 gal (240 L) |
| Operational Voltage | 24 V |
| Alternator Supplied Amperage | 50 amps |
| Hydraulic System Relief Valve Pressure | 4690 psi (32336.4 kPa) |
| Hydraulic Pump Type | two variable displacement piston pumps |
| Hydraulic Pump Flow Capacity | 88.8 gal/min (336 L/min) |
| Tire Size | 10-20-14PR |
Swing Mechanism
| Swing Speed | 11.5 rpm |
Transmission
| Transmission Type | hydrostatic |
| Number Of Forward Gears | 2 |
| Number Of Reverse Gears | 2 |
| Max Travel Speed | 18.7 mph (30 km/h) |
| Drawbar Pull | 24300 lb (11022.3 kg) |
Buckets
| Reference Bucket Capacity | 1 yd3 (0.8 m3) |
| Minimum Bucket Capacity | 0.6 yd3 (0.4 m3) |
| Maximum Bucket Capacity | 1.4 yd3 (1.1 m3) |
