Vermeer CX234
Browse All Vermeer or Mini Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Max Cutting Height | 15.33 ft in (4670 mm) |
| Shipping Height Of Unit | 7.75 ft in (2360 mm) |
| Max Loading Height | 10.83 ft in (3300 mm) |
| Max Reach Along Ground | 16.02 ft in (4880 mm) |
| Max Vertical Wall Digging Depth | 7.91 ft in (2410 mm) |
| Max Digging Depth | 10.18 ft in (3100 mm) |
| Boom/Stick Option (Hex) 1 | Boom / Stick |
Dimensions
| Width To Outside Of Tracks | 4.83 ft in (1470 mm) |
| Length Of Track On Ground | 6.6 ft in (2010 mm) |
| Ground Clearance | 1.84 ft in (560 mm) |
| Height To Top Of Cab | 7.75 ft in (2360 mm) |
| Tail Swing Radius | 4.07 ft in (1240 mm) |
Undercarriage
| Shoe Size | 11.82 in (300 mm) |
| Track Gauge | 3.84 ft in (1170 mm) |
| Max Travel Speed | 2.49 mph (4 km/h) |
| Ground Pressure | 4.41 psi (30.34 kPa) |
Engine
| Number Of Cylinders | 3 |
| Engine Make | 2334 |
| Engine Model | D 1703-E Diesel |
| Gross Power | 32 hp (23.9 kw) |
| Power Measured @ | 2500 rpm |
| Displacement | 100.5 cu in (1.7 L) |
Operational
| Operating Weight | 7054.8 lb (3200 kg) |
| Fuel Capacity | 9.6 gal (36 L) |
| Hydraulic System Fluid Capacity | 16 gal (60.2 L) |
| Hydraulic Pump Flow Capacity | 17.2 gal/min (65.1 L/min) |
