Takeuchi TB228
Browse All Takeuchi or Mini Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 14.46 ft in (4405 mm) |
| Shipping Height Of Unit | 8.03 ft in (2445 mm) |
| Max Loading Height | 10 ft in (3045 mm) |
| Max Reach Along Ground | 15 ft in (4570 mm) |
| Max Vertical Wall Digging Depth | 8.42 ft in (2565 mm) |
| Max Digging Depth | 8.42 ft in (2565 mm) |
Dimensions
| Width To Outside Of Tracks | 4.76 ft in (1450 mm) |
| Length Of Track On Ground | 4.73 ft in (1440 mm) |
| Ground Clearance | 0.99 ft in (300 mm) |
| Tail Swing Radius | 4.22 ft in (1285 mm) |
Undercarriage
| Shoe Size | 11.82 in (300 mm) |
| Max Travel Speed | 3.67 mph (5.9 km/h) |
Engine
| Number Of Cylinders | 3 |
| Engine Make | 2348 |
| Engine Model | 3TNV82A |
| Gross Power | 23.5 hp (17.5 kw) |
| Power Measured @ | 2400 rpm |
| Displacement | 81.2 cu in (1.4 L) |
Operational
| Operating Weight | 6195 lb (2810 kg) |
| Hydraulic System Relief Valve Pressure | 3045.8 psi (21000 kPa) |
| Hydraulic Pump Flow Capacity | 23.8 gal/min (90 L/min) |
Buckets
| Reference Bucket Capacity | 0.1 yd3 (0.1 m3) |
