Daewoo S015P
Browse All Daewoo or Mini Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 12.32 ft in (3755 mm) |
| Max Cutting Height | 11.16 ft in (3400 mm) |
| Max Loading Height | 7.37 ft in (2245 mm) |
| Max Digging Depth | 7.03 ft in (2140 mm) |
Dimensions
| Width To Outside Of Tracks | 3.29 ft in (1000 mm) |
| Length Of Track On Ground | 4.02 ft in (1224 mm) |
| Height To Top Of Cab | 7.38 ft in (2247 mm) |
| Tail Swing Radius | 3.91 ft in (1190 mm) |
| Removal Counterweight Clearance | 1.4 ft in (425 mm) |
Undercarriage
| Shoe Size | 9.06 in (230 mm) |
| Max Travel Speed | 1.37 mph (2.21 km/h) |
Engine
| Engine Model | L3E |
| Net Power | 16.8 hp (12.5 kw) |
| Power Measured @ | 2300 rpm |
| Displacement | 58.1 cu in (1 L) |
Operational
| Operating Weight | 3461.3 lb (1570 kg) |
| Fuel Capacity | 5.1 gal (19 L) |
| Hydraulic System Fluid Capacity | 6.9 gal (26 L) |
Swing Mechanism
| Swing Speed | 11 rpm |
Buckets
| Reference Bucket Capacity | 0.1 yd3 (0.1 m3) |
