Daewoo S75V
Browse All Daewoo or Midi Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 20.61 ft in (6280 mm) |
| Shipping Height Of Unit | 7.94 ft in (2420 mm) |
| Max Cutting Height | 20.51 ft in (6250 mm) |
| Max Loading Height | 14.08 ft in (4290 mm) |
| Max Reach Along Ground | 21.31 ft in (6495 mm) |
| Max Vertical Wall Digging Depth | 9.55 ft in (2910 mm) |
| Max Digging Depth | 13.19 ft in (4020 mm) |
| Boom/Stick Option (Hex) 1 | Boom 10'2" (3100mm)/Stick 5'11" (1800mm) |
Boom/Stick Option (Hex) 2
| Shipping Height Of Unit | 10.55 ft in (3215 mm) |
| Max Cutting Height | 21.3 ft in (6490 mm) |
| Max Loading Height | 14.85 ft in (4525 mm) |
| Max Reach Along Ground | 22.58 ft in (6880 mm) |
| Max Digging Depth | 14.51 ft in (4420 mm) |
| Max Vertical Wall Digging Depth | 10.98 ft in (3345 mm) |
| Boom/Stick Option (Hex) 2 | Boom 10'2" (3100mm)/Stick 7'3" (2200mm) |
Dimensions
| Width To Outside Of Tracks | 7.22 ft in (2200 mm) |
| Length Of Track On Ground | 6.99 ft in (2130 mm) |
| Ground Clearance | 1.2 ft in (365 mm) |
| Height To Top Of Cab | 8.63 ft in (2630 mm) |
| Tail Swing Radius | 5.58 ft in (1700 mm) |
| Removal Counterweight Clearance | 2.58 ft in (785 mm) |
Undercarriage
| Shoe Size | 17.72 in (450 mm) |
| Track Gauge | 5.75 ft in (1750 mm) |
| Number Of Track Rollers Per Side | 5 |
| Number Of Carrier Rollers Per Side | 1 |
| Number Of Shoes Per Side | 38 |
| Max Travel Speed | 2.93 mph (4.7 km/h) |
| Ground Pressure | 5.4 psi (37.24 kPa) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2348 |
| Engine Model | 4TNV98-XDB |
| Net Power | 52.3 hp (39 kw) |
| Power Measured @ | 1900 rpm |
| Displacement | 202.5 cu in (3.4 L) |
| Max Torque | 173.4 lb ft (235 Nm) |
| Torque Measured @ | 1425 rpm |
| Aspiration | naturally aspirated |
Operational
| Operating Weight | 17637 lb (8000 kg) |
| Fuel Capacity | 29.1 gal (110 L) |
| Cooling System Fluid Capacity | 2.7 gal (10 L) |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 39.7 gal (150 L) |
| Engine Oil Capacity | 2.6 gal (9.7 L) |
| Swing Drive Fluid Capacity | 0.4 gal (1.5 L) |
| Hydraulic System Relief Valve Pressure | 3980 psi (27441.2 kPa) |
| Hydraulic Pump Flow Capacity | 35.7 gal/min (135 L/min) |
Swing Mechanism
| Swing Speed | 9.6 rpm |
Buckets
| Reference Bucket Capacity | 0.4 yd3 (0.3 m3) |
| Minimum Bucket Capacity | 0.2 yd3 (0.2 m3) |
| Maximum Bucket Capacity | 0.4 yd3 (0.3 m3) |
