Liebherr A924CHD
Browse All Liebherr or Material Handler Models
Contents:
Boom/Stick Option (Mat) 1
| Max Height | 42.66 ft in (13000 mm) |
| Max Reach Along Ground | 37.73 ft in (11500 mm) |
| Max Depth | 10.83 ft in (3300 mm) |
| Boom/Stick Option (Mat) 1 | 6.8m boom / 5m stick |
Boom/Stick Option (Mat) 2
| Max Height | 45.94 ft in (14000 mm) |
| Max Reach Along Ground | 41.02 ft in (12500 mm) |
| Max Depth | 14.11 ft in (4300 mm) |
| Boom/Stick Option (Mat) 2 | 6.8 boom / 6m stick |
Boom/Stick Option (Mat) 3
| Max Height | 36.09 ft in (11000 mm) |
| Max Reach Along Ground | 41.67 ft in (12700 mm) |
| Max Depth | 19.36 ft in (5900 mm) |
| Boom/Stick Option (Mat) 3 | 6.8m boom / 5m stick and grapple model 65 |
Dimensions
| Ground Clearance | 0.84 ft in (255 mm) |
| Shipping Length | 33.31 ft in (10150 mm) |
| Undercarriage Width | 9.81 ft in (2990 mm) |
| Shipping Height | 10.93 ft in (3330 mm) |
| Upperstructure Clearance | 4.63 ft in (1410 mm) |
Wheel Undercarriage
| Wheelbase | 9.85 ft in (3000 mm) |
| Width W/ Stabilizers On Ground | 15.42 ft in (4700 mm) |
| Tire Size | 12.00-20 |
| Steering Angle | 30 degrees |
Engine
| Engine Make | 2245 |
| Engine Model | D 934 L |
| Gross Power | 184 hp (135 kw) |
| Displacement | 427.2 cu in (7 L) |
| Aspiration | turbo-charged and after-cooled reduced emissions |
Operational
| Operating Weight W/O Attachment | 69550 lb (31547.4 kg) |
| Fuel Capacity | 105.7 gal (400 L) |
| Hydraulic System Fluid Capacity | 113.6 gal (430 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 amps |
Swing Mechanism
| Swing Torque | lb ft (74 Nm) |
| Swing Speed | 8 rpm |
Transmission
| Max Speed | 12.5 mph (20 km/h) |
Hydraulic
| Pump Type | Liebherr variable displacement, swash plate double pump |
| Pump Capacity | 56.8 gal/min (215 L/min) |
