John Deere 2054
Browse All John Deere or Log Loader Models
Contents:
Boom/Stick Option (Lgl) 1
| Shipping Length | 45.02 ft in (13720 mm) |
| Shipping Height | 10.83 ft in (3300 mm) |
| Max Height | 41.25 ft in (12570 mm) |
| Max Reach At Ground Level | 36 ft in (10970 m) |
| Max Depth Below Ground | 21.26 ft in (6480 mm) |
| Boom/Stick Option (Lgl) 1 | live-heel |
| Max Lift Capacity Over Front At Ground Level | 21100.45 lb (9571 kg) |
Boom/Stick Option (Lgl) 2
| Shipping Length | 46.2 ft in (14080 mm) |
| Shipping Height | 10.83 ft in (3300 mm) |
| Max Height | 39.24 ft in (11960 mm) |
| Max Reach At Ground Level | 33.99 ft in (10360 mm) |
| Max Depth Below Ground | 19.23 ft in (5860 mm) |
| Boom/Stick Option (Lgl) 2 | articulating grapple |
| Max Lift Capacity Over Front At Ground Level | 21384.84 lb (9700 kg) |
Dimensions
| Overall Width | 11.91 ft in (3630 mm) |
| Ground Clearance | 2.34 ft in (711 mm) |
| Tail Swing Radius | 9.85 ft in (3000 mm) |
| Height To Top Of Cab | 15.46 ft in (4710 mm) |
Undercarriage
| Track Gauge | 9.59 ft in (2920 mm) |
| Max Speed | 3.42 mph (5.5 km/h) |
| Shoe Size | 27.96 in (710 mm) |
| Max Drawbar Pull | 44420.94 lb (20149 kg) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2240 |
| Engine Model | 6068T |
| Net Power | 140.9 hp (105 kw) |
| Net Torque | 427.1 lb ft (579 Nm) |
| Power Measured @ | 2150 rpm |
| Displacement | 414 cu in (6.8 L) |
Operational
| Operating Weight | 69187.7 lb (31383 kg) |
| Fuel Capacity | 269 gal (1018 L) |
| Cooling System Fluid Capacity | 6.3 gal (23.5 L) |
| Engine Oil Capacity | 5.1 gal (19 L) |
| Hydraulic System Fluid Capacity | 34 gal (128.7 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 45 amps |
Swing Mechanism
| Swing Speed | 13.3 rpm |
| Swing Torque | 41923.1 lb ft (56840 Nm) |
Hydraulic
| Pump Type | variable axial-piston |
| Pump Flow Capacity | 115.8 gal/min (438 L/min) |
| Relief Valve Pressure | 4980 psi (34335.9 kPa) |
